Zh24d-2

Starting at $15,900

MSRP on entry package, transportation and preparation fees may vary based on selection.

All ZH12G models come equipped with a 24 HP Kubota D902 diesel engine, 4 post removable canopy, u-boom, mechanical joysticks and glow plugs.

  • Operating Weight – Rubber Tracks 3000 lbs

    Operating Weight – Steel Tracks 3600 lbs

    Engine Kubota D902

    Engine HP 24 HP

    Travel Speed 3.5km/h

    Machine Width 46″

    Machine Height 7’2″

    Ground Clearance 5 1/2″

    Track Length 60″

    Track To Blade 72″

    Track Width 7″ (9″ optional)

    Max Digging Depth 6′ 2″

    Max Dumping Height 7’6″

    Max Reach 10’6″

    Max Digging Radius 12′ 3″

    Bucket Size 16″ Tooth

    Hydraulic Flow Rate 8.8 GPM

    • Enclosed Cab with fans and stereo *no heat or a/c

    • Side Swing

    • 2 Speed

    • Retractable Tracks

  • Powertrain Warranty items consist of the engine, both drive motors, hydraulic pump, swing motor, and central pivot valve body. warranty does not cover wear items such as lines, cylinders, tracks, pins, blades, seat, undercarriage, etc.
